Heavy Duty Commercial Swing Gate

Product reference:

BA1.SG1

Swing gates are a highly-secure and simple access control solution that are locked into place with a padlock. The swing gates are fabricated from heavy-duty steel and galvanised as standard to provide a durable, high-strength barrier.

Swing gates provide controlled access and security to car park entrances, farm land and industrial estates. Catch posts are supplied as standard.

· Available in 3 to 7 metre spans.

· Fully bespoke sizes and designs available by request.

· Heavy-duty 100 x 50mm gate frame.

· 100 x 100mm catch post.

· All steel hot dip galvanised as standard.

· Available powder coated in any RAL colour.

· Reflective banding and warning signs available.

· Padlocks not supplied.

We also supply double leaf, or kissing gates, which feature two gates hung at either end, to cover a greater distance without the risk of sagging.

Root fix and base plate versions available. Recommended root fixing depth 600mm. Base plate dimensions: 450 x 450 x 10mm with Gusset steel construction.

Select your required size below:

The specification for your selected product is shown in the table below:

Attribute	Value

Reflective Banding

Select the reflective banding options for your barrier or gate system. All of the banding is Class 2 retro-reflective which is highly reflective & has excellent weatherproof properties.

Gate Colour

Select your required gate colour. Our gates can be powder coated in any colour, so if you require a specific colour which isn't listed then please contact us with the details.

The colour shown has been matched as closely as possible and does not serve as a standard for RAL colour products as it depends on your monitor. Use offical RAL colour product chart for reference.
